| Details about selected cell |
| NeuroMorpho.Org ID : | NMO_07297 |
| Cell Name : | SB17L2 |
| Archive Name : | Jefferis,DIADEM |
| Species Name : | drosophila melanogaster |
| Strain : | Not reported |
| Structural Domains : | No Dendrites, No Soma, Axon |
| Physical Integrity : | Axon Complete |
| Morphological Attributes : | No Diameter, 3D, Angles |
| Min Age : | Not reported
|
| Max Age : | Not reported
|
| Gender : |
Male/Female
|
| Min Weight : | Not reported
|
| Max Weight : | Not reported
|
| Development : | adult |
| Primary Brain Region : | antennal lobe |
| Secondary Brain Region : | glomerulus VC2 |
| Tertiary Brain Region : | glomerulus DL1 |
| Primary Cell Class : | principal cell |
| Secondary Cell Class : | uniglomerular projection |
| Tertiary Cell Class : | iPN |
| Original Format : | Amira.asc |
| Experiment Protocol : | in vivo |
| Experimental Condition : | Control |
| Staining Method : | green fluorescent protein |
| Slicing Direction : | whole mount |
| Slice Thickness : | Not applicable
|
| Tissue Shrinkage : |
Not reported
|
| Objective Type : | oil |
| Magnification : | 40x |
| Reconstruction Method : | Amira |
| Date of Deposition : | 2010-08-29 |
| Date of Upload : | 2012-05-17 |
| Persistence Vector : | SB17L2.pvec |
| Note : | Reconstruction contributed to the DIADEM Challenge |
|
|
| Reference Article |
| Related Article Reference : | Comprehensive maps of Drosophila higher olfactory centers: spatially segregated fruit and pheromone representation |
|
|
|
|
| Measurements |
| Soma Surface : |
N/A |
| Number of Stems : |
1 |
| Number of Bifurcations : |
18 |
| Number of Branches : |
37 |
| Overall Width : |
35.28 μm |
| Overall Height : |
105.92 μm |
| Overall Depth : |
57 μm |
| Average Diameter : |
1.01 μm |
| Total Length : |
321.11 μm |
| Total Surface : |
1055.57 μm2 |
| Total Volume : |
303.56 μm3 |
| Max Euclidean Distance : |
116.46 μm |
| Max Path Distance : |
141.03 μm |
| Max Branch Order : |
13 |
| Average Contraction : |
0.92 |
| Total Fragmentation : |
203 |
| Partition Asymmetry : |
0.64 |
| Average Rall's Ratio : |
1.42 |
| Average Bifurcation Angle Local : |
89.3° |
| Average Bifurcation Angle Remote : |
83.36° |
| Fractal Dimension : |
1.04 |
|
|
|
|
|
